Paired temperature sensors – qualified meters


Paired temperature sensors – qualified meters

Sensit s.r.o. manufactures paired temperature sensors, including thermowells that are delivered as accessories, in compliance with the Directive 2004/22/EC (MID) of the European Parliament and of the Council on measuring instruments implemented in the legal order of the Czech Republic by the Government Order No. 464/2005 Coll. At the same time, the sensors meet the requirements of CSN EN 60 751 and CSN EN 1434 standards.

Identification of sensors is provided by type plates in red and blue colours that together with blue and red insulation tubes, installed on ends of the cable provide easy identification of sensors for supply and return branches of the distribution piping. Stainless steel thermowells can be delivered to the sensors as accessories.

Producers of calorimetric meters, heating plants, metrologic laboratories as well as installation companies, supported by sale warehouses of our business repre- sentatives in the Czech Republic, Slovakia and other countries not only inside the EU, are important customers of the company Sensit s.r.o.

TP 11 E
TP 11 E
TP 11 E
TP 15
TP 15
TP 15
TP 16
TP 16
TP 16
Accessories
Accessories
Accessories

The paired temperature sensors of Sensit TP15, TP11E, and TP16 series are especially suitable for heat flow measurement systems where applications with thermowell are required. Their advantages are namely in a great number of various models, relatively small dimensions, a possibility of any cable length, however, always in compliance with technical standards of the given model. Measuring range: 0 to 180 °C; 0 to 150 °C.

Typ Casing diameter  Casing length  JTP thermowells
Thermowell length  Thermowell thread
TP 11E 5,5 ± 0,5 mm 35 ± 5 mm 36, 86, 136, 176 mm G1/2“; M20x1,5
TP15 / TP15A / TP15B 6,0 mm TP15: 65, 105,140,230 mm
TP15A: 120/91, 175/146
TP15B: 120/83, 140/90
TP15: 65,105,140,230 mm
TP15A: 91,146 mm
TP15B: 83,90 mm
G1/2“; M20x1,5
TP16 / TP16A TP16: 6 ± 1 mm
TP16A: 3,6 ± 0,005 mm
TP16: 105,140,230 mm
TP16A: 97,133 mm
TP16:105,140,230 mm
TP16A: 88,124 mm
G1/2“; M20x1,5

Párované snímače teploty pro přímý ponor

TP 13
TP 13
TP 13
Installation using a valve VEXVE
Installation using a valve VEXVE
Installation using a valve VEXVE

The main advantage of the sensors can be found in their fast time response to change of temperature; this enables e.g. recording of very fast dynamic changes in ap- plication of warm service water. Their construction and design allow direct installation of sensors into piping without use of any thermowells.
Measuring range: 0–180 °C; 0–150 °C

Typ Casing diameter  Casing length  JTP thermowells
Thermowell length  Thermowell thread
TP13 / TP13A / TP13B TP13: 3,6 mm
TP13A: 5,0 mm
TP13B: 5,0 mm
27,5 mm - -
