TEMPERATURE SENSORS

Temperature sensors with small diameter of case

Dear Sirs,

On the 20th International Fair AMPER 2012, our company SENSIT Ltd. presented the NEWS – temperature sensors TG3 and TG3A, which are characterized by small diameter of case - 3 mm and fast response to temperature changes. Basic technical parameters of the sensors are:

Common parameters:
Cable: 2 x 0,205 mm2 , Insulation Teflon, 260 °C continuous
Wires: only two-wire connection of sensing elements
Case: diameter of case - 3 mm,
length of case - from 25 mm,
material of case - stainless steel 1.4301 (17240)

The different parameters:

Type of sensor TG3 TG3A
Temperature range From -50 to 200 °C From -50 to 260 °C (short time 300 °C)
Protection IP IP 67 IP 64
Recommended for universal use dry areas



 Snímače teploty s malým průměrem pouzdra

SENSIT s.r.o. - Temperature sensors Pt 100, Pt 500, Pt 1000,
Ni 1000, NTC 20 kΩ, NTC 10 kΩ and others; Humidity sensors;
Flow sensors

Development, production and sale of Temperature sensors, Humidity sensors, Flow sensors, Thermostats, Converters, Digital thermometers, Switches and other measuring equipment for use in the following applications:

  • Control of heating systems
  • HVAC equipment
  • Homebuilding
  • Energy Systems
  • Heat meters
  • Wheel truck vehicles
  • Rubber Industry
  • Automotive Technology
  • Home appliances
  • Food processing Industry
  • Health service



Principal classification of the products

According to the sensing element type:
According to the output signal:
Nickel types
  • Ni 1000 / 5000 (e. g. LANDIS)
  • Ni 1000 / 6180 (e. g. SAUTER, SAIA, AMIT, TECO)
  • Ni 891 (e. g. JOHNSON CONTROLS)
  • Ni 2226 (e. g. STAEFA CONTROLS)
  • Ni 10000 / 5000
  • Ni 10000 / 6180
Platinum types
  • Pt 100 / 3850,
  • Pt 100 / 3911,
  • Pt 500 / 3850,
  • Pt 1000 / 3850
Thermistor types
  • NTC 20 kΩ (e. g. HONEYWELL),
  • NTC 10 kΩ, etc.
Semiconductor types
  • DALLAS 18B20,
  • KTY 81-X,
  • KTY 83-X,
  • SMT 160 - 30,
  • ADT 7301,
  • TSic 20X / 30X, etc.
Thermocouple types
  • type K,
  • type J,
  • type T, etc.
 Resistive
  • Pt, Ni
  • NTC
  • PTC
  • KTY
Current output
  • Output signal 4 – 20 mA
Voltage output
  • Output signal 0 - 10 V,
  • According to the type of Thermocouple,
  • Special (TSic, LM35)
Digital output
  • ADAM 4000 Protocol,
  • AMIT Protocol,
  • MODBUS Protocol,
  • ADT 7301,
  • DS 18B20
Frequency output
  • 1 – 5 kHz
  • 2 – 10 kHz
  • 3 – 15 kHz
  • SMT 160-30
